  BASIC INFORMATION
Product Name:Three Heads Overhead Ionizer
Part NO.:HM-8014
Product series:Ionizer
  MORE INFORMATION
【Product Description
Ionizer is an ideal means to eliminate the electro-static in a working area;
Can eliminate or neutralize static charge in a wide area or area difficult to reach;
Neutralize static charge quickly, A large air flow cover area, A large air flow speed adjusting scale;
Has a special cleaner to clean ion generator;
Ideal static charge eliminator for precise electronic products, electronics assembly line, medical treatment device, printing packing and micro-product moulding.

Technical Parameter

Operating Voltage
110V/60HZ or 220V/50HZ
Current Consumption
1.25A or 0.62A
Operating Temperature
-1050
Size
1100mm(L)×184mm(W)×110mm(H)
Weight
12.8Kg
Air Volume
120330CFM
Ion Balance
0V±10V
Air Coverage
40cm×120cm


Test Result

Testing Conditions
Test voltage1KV-100V Operating Voltage110/220V Temperature22 Test Humidity75%RH
Distance
300mm
600mm
900mm
1200mm
Left 300mm
1.8s
2.5s
5.2s
8.6s
Center
1.3s
2.2s
4.3s
7.5s
Right 300mm
1.7s
2.3s
4.8s
8.3s
